1130. RECTILINEAR MOTION fromthe rotation of an angular crank pin. A,rotating shaft carrying crank pin E; D,arm with sleeve jointed to yoke and slidingrod B. … 1131. ANGULAR SHAFT COUPLINGfor shafts out of line. The solid sleeve blockC is bored at the same angle of the shafts,and centres of bores at a dis-tance apart equal to the dif-- , ference in the plane of shaftalignment.
