Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 229

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox, 1914, leaf 229
840. SOUNDING WEIGHT RELEASE for deep-sea sounding. A hollow spindle attached to the sound-ing-line encloses a hook lever, sprung out by a spring.A spindle, with an impact head, slides behind the leverand releases the ball at the moment the head strikesthe bottom. 841. SAMPLER SOUND-ING WEIGHT.—The… … 842. Cups closed.

Mechanical movements
