Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 319

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox, 1914, leaf 319
1249. RAILWAY STEAMSHOVEL, the Bucyrus model.For railway or other excavating onmovable trucks. 3o8 MINING. … 1250. MAGNETIC ORESEPARATOR, Hoffmantype. The pulverized ironore is fed to a travelling ap-ron, which passes over a seriesof magnets beneath the apronand over a drum where themagnetized iron particles areheld to the belt until they pass the bottom side of the drum. The unmagnetized particles are…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
