Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox (1914)
Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 323
1259^. GARBAGE FURNACE.—Plan and elevation. The garbagefalls through openings at the topand is divided on a curved partinghearth and dried by the heat of thefire on the grate and then slides orto the grate to be burned. Coalmay also be used to facilitate theburning. Plan and vertical section.… … 1259^. AIR BLAST FOR HAULAGE.—Twogrooved d r u m swith gears and anintermedi-ate b a 1 -ance gear and fly-wheel. The driv-ing shaft geared tothe hauling drum;brake wheel andband on the samedrum shaft. Shaftsare horizontal. Planand side view. MOVING COAL, slack anddust. An engine and directconnected…
Mechanical movements
