556. WATER METER.— Union water me-ter model. The water passes through a rotarymotor with equalizing gear, from which the dialpointers are driven by a clock train and counter. … 557. DISC WATER METER, Herseymodel. The disc piston, A, oscillates by the-passage of water through the disc chamber.The spindle of the disc, by its oscillatingmovement, rotates the crank and gears of theindex-wheel train. HYDRAULIC POWER AND DEVICES. i;i
