Mechanical movements, powers, devices and appliances (1901)
Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley & company · leaf 285
1123. VARIABLE CRANK THROW by aslotted sector on a face plate. 276 MOTION AND DEVICES CONTROLLING MOTION. … 1124. VARIABLE CRANK THROW by a.movable pin block in a slotted face plate and trans-verse screw. 1125. VARIABLE RADIUS LEVERfor reciprocating motion of a shaft from acontinuous motion of a crank pin.
Mechanical movements
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
