Mechanical movements, powers, devices and appliances (1901)
Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley & company · leaf 328
l is alike, and in itselfa universal joint for 45° . Both to-gether equal to 90°. 1297. BALL SOCKET UNIVER-SAL JOINT.—A ball with groovesaround it at right angles and bearingin the spherically recessed ends of theshafts. Straps fitted in the grooves,and screwed in slots in the shaft, holdthe ball… … 1299. RIGHT-ANGLE SHAFT COUPLING, Hobson and other patents. Right-anglecrank pins revolve and slide in holes in the shaftcouplings. 1300. RIGHT-ANGLE SHAFT COUP-LING, Hobson patent.—A number ofright-angle steel rods move freely in per- forated guide flanges on the ends of shafts that run atright…
Mechanical movements
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
