Mechanical movements, powers, devices and appliances (1901)
Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley & company · leaf 38
n 53. STEERING GEAR.—A hand wheel and drum on a shaft, carrying a rope rove throughguide pulleys and attached to the tiller. 54. JUMPING MOTION given to a weight,or other body, by a pin wheel and bell-cranklever. 30 TRANSMISSION OF POWER. M. 55. ROPE SPROCKET WHEEL, several modi-fications of which…
Mechanical movements
