MAUSER RIFLE.— Magazine in theforestock. The slid-ing breech blockencloses the firing-spring plunger andraises the cartridgelever A. 396 MISCELLANEOUS DEVICES. … 1648. WINCHESTER MAGAZINE RIFLE.— The breech lock slidesin line with the barrelby a toggle link, oper-ated by the breech le-ver, which also operatesthe cartridge lever, rais-ing the cartridge to its position for charging. Drawing back of the breech block carries the hammer back to its firing…
