1531a. ELLIPSO-GRAPHIC T U R N -TABLE. — The tablesits upon a trammelframe, which moves abar with gimbal yokeand sliding rod to carrythe pen or pencil. IMakes an ellipse froma circle to a straightline. 1531&. ELLIPSOGRAPH.—A pairof dividers with points perforated likethe eye of a needle allows…
