Mechanical movements, powers, devices and appliances; (1903)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N.W. Henley & co. · leaf 404

An illustration from Mechanical movements, powers, devices and appliances;, 1903, leaf 404 — A breech block, operated by ahandle, is pulled back toallow the cartridge to becharged by hand, when thebreech and the block arelocked. The hammer strikesa firing pin within the breechblock. REMINGTON MAGAZINE GUN. — The magazine is-placed in the stock under thebarrel. The cartridge is liftedby a… … /-^^^ ^^^ J HOTCHKISS MAGAZINEGUN.—The reserve cartridgesare carried in the gun stockand forwarded by a light spring.The breech bolt draws back bythe handle, when the cartridgeis raised and pushed forward into the barrel. Centre pin spring hammer.

Mechanical movements
