/-^^^ ^^^ J HOTCHKISS MAGAZINEGUN.—The reserve cartridgesare carried in the gun stockand forwarded by a light spring.The breech bolt draws back bythe handle, when the cartridgeis raised and pushed forward into the barrel. Centre pin spring hammer. … LEBEL RIFLE.— Magazine under thebarrel in the extensionof the stock. A slidingbreech block and pis-ton hammer.
