Mechanical movements, powers, devices and appliances; (1903)
Hiscox, Gardner Dexter, 1822?-1908 · New York, The N.W. Henley & co. · leaf 70
190. YARROW WATER TUBE BOILER.—Inclined sections of straight tubes from water-headers each side of the hre grate to a large steamdrmn above. Iron casing lined with fire tile.This design is for a marine boiler. 191. BOYERS WATERTUBE BOILER. —Furnacewalls are coils of pipe. Coilsover the fire are… … 192. HAZELTON BOILER.—A centralL, ) vertical drum in which tubes, with closed ends,are screwed radially. The grate is beneath the^^-^ radial tubes and around the base of the drum. 193. CLIMAX BOILER.—A central vertical water and steam drum, with benttubes expanded in it, and inclined to facili-tate…
Mechanical movements
