Mechanical movements, powers, devices and appliances; (1903)
Hiscox, Gardner Dexter, 1822?-1908 · New York, The N.W. Henley & co. · leaf 72
202. SERVES BOILER TUBE.—The pro-jecting ribs enlarge the area of the fire surface ofthe tube. … 203. SHAKING AND TIP-PING FURNACE GRATE, Tupper model. Each sectionrocks on trunnions by a handlever and connecting bar. 204.
Mechanical movements
