Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 110

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 110
STCAM WATER … 373. SHAEFFER & BUDEN-BERG INJECTOR.—An exhaust in-jector by which the exhaust steamestablishes a feed jet to the boiler. Ahinged section in the combining tubeallows a free flow of steam to draw thewater; the hinged section then closes andthe injector operates the same as othersfor feeding a…
