Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 136

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 136
MOTIVB POWER. 129 … 463^. GASOLINEATOMIZER, of theconstant feed type.—A, receiving tank; B,float; C, counterweight and valve; E,jet nozzle; H, air in-let ; G, perforatedcone with air regulat-ing cap L.
