Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 178

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 178
637. AIR COM-PRESSOR.—Pat-tern of the Inger-soU-Sergeant DrillCo. Operated by aPelton wheel. Ver-tical section. 6^^. Plan. … 639. AUTOMATIC AIR COMPRES-SOR, Bennet model.Showing the valve gear ofa simple lever connectedby link to the eccentric. 172 AIR POWER APPLIANCES. 18, mxcvoM KPt

Mechanical movements
