Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 182

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 182
650. AIR COMPRESSING CYLIN-DER, with vertical lift valves,water-jacketed cylinder andheads. Ingersoll-Sergeant 3 model. AIR POWER APPLIANCES. 175 … 651. AIR COMPRESSOR GOVERNOR.— Controlling the speed by the ordinary action ofthe governor balls, and also reducing the com-pressor to minimum speed when the air pressurebecomes excessive. The ball and lever at theright are lifted by the air pressure in the smallpiston, and force the valve rod and…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
