Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 228

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 228
855. STEAM FIREENGINE. Vertical tubu-lar boiler. Vertical steampump, with yoke connec-tion to fly-wheel crank. Gould pattern. … 856. JACKETLESS GASOLINE CARRIAGEMOTOR, with two cylinders inline on two cranks at oppositepoints. Four-cycle type. Explo-sion in cylinders simultaneously,reducing vibration. Cylindercooled by air circulation over theradial ribs.

Mechanical movements
