Practical hand book of gas, oil and steam engines, stationary, marine, traction; gas burners, oil burners, etc.; farm, traction, automobile, locomotive; a simple, practical and comprehensive book on the construction, operation and repair of all kinds of engines (1916)
Rathbun, John B. [from old catalog] · Chicago, Charles C. Thompson co · leaf 266
Fig. 111. Side Elevation of Mea Magneto, Showing the Magnets, andCradle in Which the Magneto Swings When Advanced and Retarded. familiar with automobiles. They are the difficulty of crankinga motor on one of the average high tension magnetos, if thespark is fully retarded, and of operating the… … 53 1 12 4 18 100 x24 Fig. 112. Longitudinal Section of Mea High Tension Magneto. neto at very low speed, particularly when it is overloaded, asfor example, in hill climbing. Attempts have therefore beenmade to obtain the spark, independent of the timing, always atthe same favorable position of the…
Internal combustion engines · Traction-engines
