Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 328

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 328
CTION CLUTCH.—Several plates of iron or steel are fitted loosely on a three-feather shaft, be-tween which plates of wood or other hard material, sometimes steel, are placed andkeyed in an ironhousing or coup-ling to moveloosely on thekeys. The coup-ling is keyed tothe next shaft in line. A follower…

Mechanical movements
