Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 333

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 333
1332. WOOD- BENDINGCLAMPS AND FORMERS.—Strips of wood are thoroughlysteamed and bent while hot overthe formers and clamped. 1332A. Offset clamp. 1333. Thill clamp. 1334. Bend clamp. 326 MILL AND FACTORY APPLIANCES. … 1335. BOILER TUBE EXPANDER.—Aseries of sets surrounding a conical driving pin, Prosser percussion type. A guard ring fixesthe proper position of the expanding grooves ofthe sectional sets to match the tube head. 1336. Longitudinal section.

Mechanical movements
