Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 39

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 39
64. VERTICAL TENSION with slides and pulley guide. CARRIAGE, 32 TRANSMISSION OF POWER. … 65-66. BELT LACING.—The straight lacing 65 should run nextthe pulley, while 66 represents theoutside of the belt. ^>ce shouldbe drawn in at a^ a, to centre ; laceeach way out and return, endingat e, Cy 66, on outside of belt. 67-68. BELT LACING.—In this style the straight side shouldrun next the…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
