1616. CENTRE GUIDE GAS HOLDER.— A, the holder.^555 3, centre guide. «, tube sliding on centre guide. B, tank. 1617. COUNTER-WEIGHTED GASHOLDER. A, the holder. B, the water seal. C, the counter weights. … 1618. EXPANDING PIPE STOPPER. - Arubber ring compressed between two flanges by abolt and thumb screw. \r^^^^^.i^J%^^^^;^ 1619. LANTERN BELLOWS DRY GASMETER.—The two pair of bellow chambers, A,A, are alternately filled with gas under the servicepressure, by which the movement of the centraldiaphragm…
