Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 409

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 409
RAIGHT LINE MOVEMENTS. 1664. OIL SWITCH MOVEMENT WITH TWOLEVERS AND ONE LINK.—Levers A and H are connectedby link E to frame K. Lever A, pivoted to frame K at B, is connected to link E 2X D.Link E, connected to lever Aat D, is connected to lever Hat F. Lever H, connected tolink E at F, is pivoted… … 1665. OIL SWITCH MOVEMENT WITH THREELEVERS AND THREE LINKS.—Levers A, E, and / areconnected by links G and L to frame O. Lever A, pivoted toframe O at B, is connected to link Q at C. Link Q, con-nected to lever A at C, is con-nected to lever E at D.Lever E, connected to linkQ at D, is pivoted to…

Mechanical movements
