Mechanics and heat; a text book for collleges and technical schools (1916)
Franklin, William S. (William Suddards), 1863-1930, Macnutt, Barry, 1878-1936, [from old catalog] joint author · New York, The Macmillan company; London, Macmillan & co., ltd. · leaf 212
hich the value is Wx, and therefore the force with which the portion is actedupon at a!af by the remainder of the beam, that is the force action across thesection a/a/, is a pure torque which is equal and opposite to Wx. ELASTICITY. (STATICS.) I97 the filaments in the upper part of the beam are… … is everywhere under longitudinal strain as shown in Fig. 90; andthe force action between contiguous parts of the beam is as shownin Fig. 91. These figures may be understood by comparing them
