Mechanics of engineering. Comprising statics and dynamics of solids: and the mechanics of the materials of constructions, or strength and elasticity of beams, columns, arches, shafts, etc (1888)
Church, Irving P[orter], 1851- [from old catalog] · New York, J. Wiley & sons · leaf 182
olved along AO and AB ; but should await the legitimateresults deduced by algebra, from the equations of conditionfor the equilibrium of a system of forces in a plane. Fewproblems in Mechanics are so simple as to admit of an imme-diate mental solution on inspection ; and guess-work should… … Fig. 171. 170 MECHANICS OF ENGINEERING. The three unknowns P, JV, and iV^ can now be found.Divide (3) by a, remembering that b : a = m, and solve forJT; substitute it in (2) and iV^ also becomes known; while Pis then found from (1) and is 23fG_/V2 Problem 2.—Fig. 172. A rod, centre of gravity at…
Mechanics, Applied · Engineering · Strength of materials
