Mechanics of engineering. Comprising statics and dynamics of solids: and the mechanics of the materials of constructions, or strength and elasticity of beams, columns, arches, shafts, etc (1888)
Church, Irving P[orter], 1851- [from old catalog] · New York, J. Wiley & sons · leaf 259
nd from JF(mom. aboutO)=0, PJ,3=Ph. Hence given Pj we may determine theother two external forces. A reaction such as P2 is some-times called a supporting force. The elements above theneutral surface NiOLSaxs in tension ; those below in com-pression (in an axial direction). 226. The Elastic… … ;/ !/ F*G. 222. FLEXURE. 247 the bounding surfaces, but was originally an internal sur-face of the beam in Fig. 221. Hence in Fig. 222 we mustput in the stresses acting on all the dFa or elements of areaof QAB. These stresses represent the actions of the bodytaken away upon the body which is left,…
Mechanics, Applied · Engineering · Strength of materials
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
