ht of beam being neglected). As before, the flexure is to be slight, and the forces are all perpendicular to the beam. The present problem is that in fig. 263, the beam being prismatic, supported at the ends, with a single eccentric load, P. We shall first disregard the weight of the beam itself.… … 302 MECHANICS OF ENGINEERING. B2—e/=0, i.e., J=B2;while from 2 (mom.)m=0 we have £I-B,x= 0 .\M = B2x=^x e I These values of J and M hold good between 0 and (7, Jbeing constant, while M is proportional to x. Hence for00 the shear diagram is a rectangle and the moment dia-gram a triangle. By…
