Mechanics of engineering. Comprising statics and dynamics of solids: and the mechanics of the materials of constructions, or strength and elasticity of beams, columns, arches, shafts, etc (1888)
Church, Irving P[orter], 1851- [from old catalog] · New York, J. Wiley & sons · leaf 510
1 and 4 on the vertical SV,and thus determine l2=(ilO.)i and 34=(Jf.^.)3. Theirnumerical values are then computed in accordance withthe scale of the moment-area diagram. The polygon A123B will be called the false polygon of the span in question, its end-segments being the end-tangents of the… … Fig. 44 of five spans, all six supports on a level, and the weight ofthe beam neglected. At the extremities A and F, as atthe other supports, the beam is not built in, but simplytouches each support in one point; hence the moments atA and F are zero, i.e., the moment curve must pass throughA and F,…
Mechanics, Applied · Engineering · Strength of materials
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
