Mechanics of the household; a course of study devoted to domestic machinery and household mechanical appliances (1918)
Keene, E. S. (Edward Spencer), b. 1864 · New York, McGraw-Hill book company, inc.; · leaf 133
heat accumulated undersuch conditions a hot-water radiatoris frequently connected with the rangeboiler through which to dispose of theexcess heat. This radiator may beplaced in any desired position and soconnected by a valve as to discontinueits use at any time.Furnace Hot-water Heaters.—It is… … Fig. 120.—The range boilerconnections when a furnacecoil is used for hot-water heat-ing. PLUMBING 123 of the water-back. The arrangement of the pipes in the rangeboiler are as before, the water entering the tank through thepipe A J circulates through the pipes B and C, receiving its heatwhile…
Heating · Lighting · Plumbing
