Training in wood-work, designed for use in manual training and technical school; consisting of three parts: carpentry, wood-turning and pattern work (1902)
Tate, James M. (James Murray), b. 1852 · Minneapolis, Minn., School Education Co · leaf 108
g the templet to test the curves.Nos. 3 and 4 may be done either on the face-plate or cut outwith the gouge. When the pieces are all formed glue theparts together, sandpaper and varnish and the box is readyfor the foundry. The core box will form a half-round coreand two are needed to form the… … Fig. 181. lowance to be made for thread cutting on the inside of elbow.To construct this pattern proceed in the following manner. Sawa piece 12 inches by 3 inches by i]/. inches. Plane one side true;saw the piece in two parts and place the dressed surfaces to- io6 MANUAL TRAINING gether and fasten…
Woodwork (Manual training)
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
