to the size of thework which it can accommodate. The indexing mechanism isunder the floor and hence out of sight. Fig. 271 gives an outhne plan view of the action of the tem-plet which is here divided in halves—one for each side of thetooth spaces. By suitable feeding mechanism, into the detailsof… … Fig. 268.—Gear hobbing machine set for spur gears.
