Model engine construction, with practical instructions to artificers and amateurs (1894)
Alexander, John Henry. [from old catalog] · London, New York, Whittaker · leaf 176
FigT Stroke Commences /^ Cenire line of 1 —__ Connecting rod/ Wf//WMMiMr\ Tiff 2 Steam pert ihll open> … / / \ O Fig. 48.—Action of Steam in Cylinder, etc. PART II. DIFFERENT TYPES OF ENGINES:STATIONARY, LOCOMOTIVE, MARINE. CHAPTER VI. BEAM, HORIZONTAL, AND VERTICAL ENGINES. - Having described trie engine in detail, how tomake and fit together the different parts, we willnow describe and illustrate a…
Steam-engines · Machinery
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
