Modern locomotive engineering, with questions and answers .. (1913)
Swingle, Calvin Franklin, 1846- [from old catalog] · Chicago, F. J. Drake & co · leaf 299
.O LOCOMOTIVE ENGINEERING Ir. e with each other, the low-pressure outside, and thehigh-pressure inside the frames. The slide valves are of the piston type, placed above STARTING VALVE … steam distribution in balanced compound cylindersFigure 135 and between the two cylinders which they are arrangedto control. A separate set of guides and connectionsis required for each cylinder. COMPOUND LOCOMOTIVES 2Q
Locomotives
