Modern cabinet work, furniture & fitments; an account of the theory & practice in the production of all kinds of cabinet work & furniture with chapters on the growth and progress of design and construction; illustrated by over 1000 practical workshop drawings, photographs & original designs (1922)
Wells, Percy A, Hooper, John, b. 1882 · Philadelphia, J.B. Lippincott Company · leaf 403
OlflCRAM- U-LUS -ttlmiMG A JUL-fl3TER.UOCK.ltNO mcTiori • … open the three tiers of drawers, the long drawer at bottom is drawn forwardabout ] inch, and the A bar then falls and causes the clips to bear upon thepins shown, thus raising the front part. The drawers contained in the cabinetare locked by pushing home the bottom drawer, and locking the same,…
Cabinetwork · Furniture making
