. Now come to angle on the right; here take H ascentre, and with any radius, as E, draw the circle,cutting at F; join it and E; draw from H parallel withE F, and you will find a correct mitre. The next question is the intersection of straight andcircular mouldings. In the present case an extreme… … ••M -v.. PRACTICAL SOLUTIONS 135 points; bisect AB and BC; drawn through intersec-tions thus made, and lines meeting in point D give acentre, from which strike the circular mitre as shown. Here it may be stated that in some cases a straightline for mitres will answer; this means when the curveis a…
