Modern carpentry and joinery : being a compilation of the very best things and most modern and practical methods known in the arts of carpentry and joinery (1910)
Hodgson, Frederick Thomas, 1836- · Chicago : F. J. Drake & Co. · leaf 141
op edge,as shown; mark FL; then join L V; cut through theselines from the back, and the mitre is complete. To cut the mitre on the rake moulding, square overany line on its back, as that of HJ; continue it acrossthe top and lower edge; take bevel X, shown aboveFig. 5, apply it here on top edge, and… … Fig. 5. Fig. 6. PRACTICAL SOLUTIONS 139 bevel W above Fig. 5, apply it here and mark 2 B; joinBA; this done, apply the same bevel on front edgeNP, and mark the plumb cut, it being parallel withthat of 2B here, or K J, Fig. 5; now cut through lineson the back, and the mitre is complete. It has…
Carpentry
Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
