Modern carpentry and joinery : being a compilation of the very best things and most modern and practical methods known in the arts of carpentry and joinery (1910)
Hodgson, Frederick Thomas, 1836- · Chicago : F. J. Drake & Co. · leaf 182
^ on the perimeter, anddraw lines from the divisions to the centre as II C;make the edges parallel with these lines. A Window With a Splayed Soffit and Splayed Jambsis shown in part elevation, Fig. 43, plan Fig. 44; and PRACTICAL SOLUTIONS 179 section Fig. 45. The linings are grooved and… … Fig. 44. be revolved upon one of its edges until it is parallelwith the front, when its real shape can be seen. Thisoperation is shown in the diagram on the right-hand
Carpentry
