d the inside finished bead-flush. The arrangement of box shutters requires thatthe shutters on the same side shall vary in width sothat they will fold into the boxes on each side of thewindow, the outermost shutter (which is the widest)then acting as the window lining. Fig. 96 shows a hori-zontal… … Fig. 97. opening. This arrangement is suitable for a thin wall,where it is undesirable to have boxes for the shuttersprojecting beyond the face of the wall. For hang-ing window shutters it is usual to use back-flap hinges;the joint at the corner of the shutters in Fig. 97 isnamed a rule joint.…
