rofile of the tetrahedronC D e inclined to the horizontal plane. From D letfall a pei-pendicular on C e produced, and it will gived as the horizontal projection of the summit of thepyramid in its inclined position. Join Ad, B d, Ac,B c to complete the figure. The vertical projection ofthe… … XVII. To construct vertical and horizontal pro-jections of a cube, the axis 1 of which are perpendic-ular to the horizontal plane. If an arris of the cube is given, it is ea.sy to find itsaxis, as this is the hypotenuse of a right-angled tri-angle, the shortest side of which is the length of an 44…
