The modern gas tractor, its construction, utility, operation and repair: a practical treatise defining every branch of up-to-date gas tractor engineering, driving and maintenance in a non-technical manner. Considers fully all types of power plants and their components, methods of drive and speed changing mechanisms. Describes design and construction as well as practical application of tractors in the field (1919)
Pagé, Victor Wilfred, 1885-1947 · New York : Scientific American Pub. Co. · leaf 217
High Tension Wireto Distributor Segment Distributor Brush- Secondary Winding Primary WJndlng- Stationary Windin Wire toIntulated Contact Platinum TippedScreui … Fig. 77.—Diagram Explaning Action of Four Cylinder MagnetoIgnition System Used on Big 4-30 Gas Tractor. high tension magneto, the various essential parts thatare in circuit are shown at Fig. 77. The magneto shownhas a revolving inductor member instead of the conven-tional form of armature and a…
Farm engines · Internal combustion engines
