The modern gas tractor, its construction, utility, operation and repair: a practical treatise defining every branch of up-to-date gas tractor engineering, driving and maintenance in a non-technical manner. Considers fully all types of power plants and their components, methods of drive and speed changing mechanisms. Describes design and construction as well as practical application of tractors in the field (1919)
Pagé, Victor Wilfred, 1885-1947 · New York : Scientific American Pub. Co. · leaf 279
COUNTERSHAFT CASi= DIFFERCNTIAL GEARING CASE/AND BRAKEDRUM … Fig. 107.—View of Transmission and jJitierential Unit VVitliCover Removed. on the differential case drive shaft, which normallyrevolves free upon it, is clutched to that member then areverse motion will be obtained. The drive from theengine is to the drive sprocket of the transmission gear-ing,…
