Modern mechanism, exhibiting the latest progress in machines, motors, and the transmission of power, being a supplementary volume to Appletons' cyclopaedia of applied mechanics (1892)
Benjamin, Park, 1849-1922 · New York, D. Appleton · leaf 133
Fig. 6. —Clay tempering-wheel. … Fig. l.-Hill friction-eluteh pulley. Fig. 2 -Link Belt Eng. Co.s disk friction-clutch. Tlie Liiik-BeU Engineerinq Co.s Disk Fridion-Chitch is shown in Fig. 2 : figure showingthe clutch in engagement, and figure disengaged. It consists of a plate-c-.Miter pulley, c(m- taining beneath its rim on one…
Mechanical engineering
