Modern mechanism, exhibiting the latest progress in machines, motors, and the transmission of power, being a supplementary volume to Appletons' cyclopaedia of applied mechanics (1892)
Benjamin, Park, 1849-1922 · New York, D. Appleton · leaf 256
Flo. 91.—Oanz & Co.s alteriiating-ciirreiit dynamo. ♦ Wit hi lilt base. + Approximate. DYNAMO-ELECTRIC MACHINES. 237 … Fig 92 —Ganz & Co s alternating current dynamo bolted to the traversers. The armature-plates are held together by ribbed bronze plates, whichalso serve to hold the armature-coil in its place. In larger armatures bronze plates are alsoinserted at intermediate points, and they serve for the…
Mechanical engineering
