f a heater can be used with the sameresult. M shows the pipe and valve thatbrings the hot water from the heater. N isthe pipe and valve that leads from the boilerto the heater. The valve in 31 is a stop andcheck combined. The pipe in N has a trip-valve that is worked by hand or made auto-matic, as… … Fig. 2.—Boiler section. No. 5. It is made direct-acting, without crank or fly-wheels, and is claimed to be the lightestdouble engine made. Its weight is but 4,000 lbs., and capacity 400 gallons per min. The dimensions are as fol-lows : Steam-cylinders, 7in X 7in. stroke; pumps,4| in. X 7 in.…
