Self-propelled vehicles; a practical treatise on the theory, construction, operation, care and management of all forms of automobiles (1906)
Homans, James E. (James Edward), b. 1865 · New York, T. Audel & Company · leaf 611
er the manner of a well-made boiler flue attachment.These air tubes, as they are called, are open to the air at top andbottom, having no communication with the interior of the cylin-drical chamber above referred to. The gasoline enters the cham-ber, from a nozzle at the end of the feed pipe and… … Fig. 438.—Plan and Part Section of a Typical Gasoline Burner for SteamCarriage Use. that will burn readily in the atmosphere. Having entered thecylindrical chamber, there is no avenue of escape for the in-flammable gas except through the circular series of pin-holes,which surround each one of the…
Automobiles
