Modern mechanism, exhibiting the latest progress in machines, motors, and the transmission of power, being a supplementary volume to Appletons' cyclopaedia of applied mechanics (1892)
Benjamin, Park, 1849-1922 · New York, D. Appleton · leaf 323
Fig. 2.—Cylinder-vertical section. 302 ENGINES, STEAM, STATIONARY EECIPEOCATING. after engine has been standing for some time. The valve A (Fig. 8) besides taking steamat the ends, has supplemental admission ports a a (Fig. 7) wliich are connected at top and
Mechanical engineering
Internet Archive · Boston Library Consortium · Public Domain Mark 1.0. Free to use for anything.
