Fig. 33.—The GiiUiiiigs compound engine. to adjust or renew the packing. The intermediate receiver has been discarded in these en-gines. The Oiddings Valve.—Fig. 34 shows the Giddings equilibrium slide-valve, used in theGiddings high-speed automatic engines. This slide-valve consists of one piece;…
