Fig. 146. Piston Valve. Q. Can an outside admission piston valve be made to runwithout an exhaust cavity in the seat?A. Yes; as shown in Fig. 146.Q. What eccentric arrangement is here necessary?A. The same as for the ordinary plain D. … Q. Can one be made with inside admission and no exhaustport? A. Yes; as seen in Fig. 147. * Not pre-admission. 246 LOCOMOTIVE CATECHISM. Q. How about the valve motion in this case?A. It must be the reverse of that where there is outside ad-mission. Q. What would happen if either of the heads of…
